F44 300cm
SKU:
F44300
EAN: 4042659135777
- Length: 300 cm
- Pipe diameter: 50 mm
- Wall thickness: 2 mm
- TÜV Certified
- Conical connectors included
Non-binding price recommendation
€542.00
Interested in this product?
Register now
The F44 truss series by Global Truss is a TÜV approved 4-point system with an external dimension of 40cm. The system off ers an outstanding load capacity and low deflection, ideal for complex constructions with high loads, along with stage systems and permanent installations. A maximum span of up to 20 meters can be created with this system.
The F44 truss is built with 50 x 2mm main tubes and 25 x 3mm diagonal braces of aluminium. The truss pieces are connected with the included conical connectors. This truss and all other Global Truss series can be powder coated in every RAL colour.
General
| Colour: | Aluminum |
|---|---|
| TÜV certificate: | Yes |
| Material: | Al EN AW-6082 T6 |
Technical Data
| Number of points: | 4-point |
|---|---|
| Edge dimension: | 40 cm |
| System: | F44 |
| Type: | straight |
| Truss length: | 300 cm |
Main pipe
| Diameter main pipe: | 50 mm |
|---|---|
| Wall thickness main pipe: | 2 mm |
Brace
| Diameter Brace: | 25 mm |
|---|---|
| Wall thickness Brace: | 3 mm |
Hardware
| Dimensions (L/W/H): | 3000 x 400 x 400 mm |
|---|---|
| Weight: | 17,90 kg |
Shipping Data
| Length: | 3000 mm |
|---|---|
| Width: | 400 mm |
| Height: | 400 mm |
| Weight: | 24.28 kg |
| PU: | 1 |
