F34 P 50cm for motor hoist
SKU:
F34050P-M
EAN: 4251665202902
- More lifting height
- Compatible with F34 and F34P
- Length 50cm
- Conical connectors included
Non-binding price recommendation
€250.00
Interested in this product?
Register now
The F34 50cm traverse for motor hoist allows the direct installation of an electric chain hoist inside the truss.
On one side, the truss has no diagonal. This way the engine can be mounted with a gizmo inside the truss. This allows better utilization of the lifting height.
The truss piece is compatible with the F34 and F34P systems.
Please check in advance the dimensions of your chain hoist!
General
| Colour: | Aluminum |
|---|---|
| TÜV certificate: | No |
| Material: | Al EN AW-6082 T6 |
Technical Data
| Number of points: | 4-point |
|---|---|
| Edge dimension: | 29 cm |
| System: | F34P |
| Type: | special part |
| Truss length: | 50 cm |
Main pipe
| Diameter main pipe: | 50 mm |
|---|---|
| Wall thickness main pipe: | 3 mm |
Brace
| Diameter Brace: | 20 mm |
|---|---|
| Wall thickness Brace: | 2 mm |
Hardware
| Dimensions (L/W/H): | 500 x 290 x 290 mm |
|---|---|
| Weight: | 5,20 kg |
Shipping Data
| Length: | 500 mm |
|---|---|
| Width: | 300 mm |
| Height: | 300 mm |
| Weight: | 5.86 kg |
| PU: | 1 |
